REXC600; 12x2V=24V

$5,999.00

Narada datasheet 2V series

REXC SERIES DATASHEET（2V）

Narada datasheet REXC1000

REXC-1000_v2

REXC600OG



Description

24V Narada REXC-600 battery



This battery comes with 12 times 2V 600Ah cells.  In a 24V set-up, this battery would have a capacity of 24×600=14.4kWh or 28.8kWh in a 48V set-up at a 10h discharge rate. The 120h discharge capacity is 720Ah. This is the overall capacity and the usable storage is about 50% of this value.

Bulk size: 12 cells including connections cables for 24V in an international shipping package from the factory. It can be handled with normal forklifting machines with a weight of 582kg with no special logistics requirements.



Installation

This capacity is a good choice for 48V full off-grid houses with low power demand and in 24V for summer holiday homes. A rack is available on request.

Example: 48V combination with

  • 12 x 360Wp solar panels
  • 6 x 4.2m rails, fixtures, clamps and cables
  • 4000W low frequency inverter/charger
  • MPPT150/70 charge controller

We do supply full systems and provide installation support. We either consult your preferred electrician or we use our inspector level installers.



Specifications

2V Valve Regulated Lead Acid (VRLA) with a lead-carbon chemistry
600 Ah at C10; 720 Ah at C120
Dimensions L: 231mm D: 180mm H: 408mm
Weight: 46kg



Warranty

Narada provides a 5 year pro-rata* warranty when used under specified conditions.

*Pro-rata warranty depreciates the value of warranty by 20% annually – by either restoring the capacity or deducting the compounded value in a new purchase. EWe provide you our T&C´s on each purchase or on request.



Service Life

This battery can achieve a service life of up to 25 years. This requires a well engineered system and a specified cycling of the battery. A typical off-grid layout would have a minimum of 4kWp solar and a generator back-up to avoid any partial stages of discharge (PSoC) in dark periods. If you are not sure how to design a layout, just get in touch and we help you to optimise your whole system.



Category:

Description

This is a 24V Narada REXC600 battery comes with 12 individual 2V cells. The capacity is 600Ah at C10 and 720 at C120.

Narada do provide a five year pro-rata warranty conditioned to specified usage. Specs are within the instruction manual and is a parts of our terms and conditions. This offer comes with a free delivery within acceptable reach from Christchurch. If you consider self-pickup, be aware of the high weight of about 570kg per crate.

When it comes to an off-grid system, the REXC is one of the best choices. It can cycle deeper, lives longer and can draw more Ampere than a same size Gel or AGM battery. If you are using it right – (I can advise you), this battery can live 20 to 25 years, even when daily cycled. These combined benefits makes a lead-carbon superior even to much more expensive lithium technology. No hassle with re-watering etc and can be operated on its side as well. The REXC series is special designed for hard cycle. It is more than “just” lead-carbon!

As the off-grid.nz specialists in New Zealand, we hold advanced knowledge in batteries and energy systems in general. We tend to have always the material on hand to build a complete system with panels, fixtures, cables and electronics. We engineer, consult and source all sizes of systems worldwide but work with local installers and experts to get your system not only just going but also for the lowest possible price. Our solar inspector takes care on your installation when you order a complete system to guarantee you a top quality fully compliant system installed. We get full Narada factory support and are named as a preferred supplier. We are based in Christchurch and cover complete New Zealand.
